Description
Waveform: Self-Compensating Output Pulse Envelope (SCOPE) optimized biphasic escalating waveform compensates energy, slope and duration for patient impedance
Patient analysis system Method: Evaluates patient’s ECG, electrode contact integrity and patient impedance to determine if defibrillation is required Sensitivity/Specificity: Meets IEC/EN
60601-2-4
Impedance range: 20-230 ohms
Energy selection
Pad-Pak:
Shock 1: 150J
Shock 2: 150J
Shock 3: 200J
Pediatric-Pak:
Shock 1: 50J
Shock 2: 50J
Shock 3: 50J
Charge time (typical):
150J in < 8 seconds
200J in < 12 seconds
